2523C

DE175BS4

175kW (235hp) @ 2200 rpm

850 Nm @ 1200 - 1600 rpm

6 Nos., 6372 cc

BSIV

G131, 9F + 1 R, Mechanical, Synchromesh Gears

Single dry plate, Hydraulic control with clutch booster, 395mm

IF 6.6, Reverse elliot

RA1 - IRT 390-11 Hypoid gears/ RA2 - IRT 390T-11, Topoid gears

5.375

25,000 kg

Channel Section with cross members

288 mm x 70 mm x 9 mm

Parabolic leaf spring with 2 hydraulic shock absorbers

Inverted Semi elliptical tandem bogie

Standard on both axles

 Pneumatic, Foot operated, Dual line with ABS

Pneumatically operated hand control valve

7.50 x 20, 11.00 x 20 - 16 PR/ 11.00 R20 - 16 PR

Hydraulic Power assisted

Day cabin, Tiltable

290 litres

60 litres

24 V Electrical System

2 x 12 V, 120 Ah

53%

60 km/h

15.5 m

Fully built 16 Cu.M Box Tipper

Fully built 14 Cu.M Box Tipper

Comfort Pack (HVAC) & RMC Pack
